Honda Pioneer 520 8" Portal Gear Lift

Upgrade Your Honda Pioneer 520 with Huge 8" Portals
Your Pioneer could use a boost literally. SuperATV's 8" Portals for the Honda Pioneer 520 take your machine from a minor player to a major problem. A problem for the terrain, that is. These muscular portals give you a gigantic 8-inch lift and a gear reduction all in one. Trails, creeks, mud wherever you ride, GDP Portals for SuperATV can help you dominate.

• Gives you an 8" lift and a gear reduction in one package
• 45% or 60% gear reduction
• Maintains OEM suspension angles
• REQUIRES aftermarket suspension to clear 22" wheels and matching tires

45% or 60% Gear Reduction
A 45% or 60% gear reduction transforms your Pioneer's torque. It gives you back the power that your gigantic tires could steal. If you're taking on tricky trails or deep mud, you'll love the power your portals deliver.

GDP Portals Save Your Drivetrain
GDP Portals put the gear reduction directly in the hub. This protects your entire drivetrain from unnecessary stress. Your axles, diff, prop shaft, and transmission will be protected instead of torn to bits.

Honda Portals That Are Built Tough
GDP Portals are built to be the toughest. They use 5/16" advanced steel alloy backing plates and precision-engineered aluminum housings so you can ride the way you want.

• Our housings are reinforced for gear retention and optimized for oil flow
• Advanced steel alloy backing plates are stronger than chromoly
• Enhance with Portal Blood gear oil formulated for GDP Portals
• There are no gimmicks and no vents because vents do more harm than good we know because we tested them

Advanced Gaskets, Seals, and Bearings
Our portals use:

• Advanced gaskets and O-rings with excellent oil resistance and low deterioration rates
• A sealed input gear and double-lipped output seal
• 100% sealing coverage throughout so you can forget about oil leaks
• Double-angular contact output bearings to prevent premature wear
• Roller idler and drive bearings to maintain perfect gear meshing

Top-Rated Customer Service
Still need a little help getting exactly what you need No worries we've got a dedicated team just for portal support. Give us a call so we can get the perfect set of portals in your hands today.

8" Portal Gear Lift Includes:

• (4) Assembled portal hub boxes complete with 9310 gears, seals, output shaft, gaskets, and thrust bearings
• (4) Universal hubs and precision-ground stainless steel slotted rotors with lugs
• (4) Specialized steel alloy backing plates
• (2) Steel caliper mounting plates
• (4) Caliper adapter plates
• Steering stop kit
• Extended brake lines
• All required hardware, including recessed castle nut socket

Max Tire Size Recommendations
Max Tire Size	Required Suspension Setup with GDP Portals
32"	Stock
If you need help figuring out which gear reduction is right for you, check out our portal gear reduction calculator.		Max tire sizes are measured at full compression and full turn. The given tires sizes are the largest we fit without rubbing. With minor trimming or a small amount of rub, larger tire sizes can be used.

Patent # 8,985,264, 11,015,681, 11,299,042, 11,554,662, 12,005,776
