ATG 500W Class D Monoblock Amplifier

Sale price $152.99 USD Regular price $169.99 USD
10% off
SKU: ATGM1
Monoblock Class D Amplifier Output Power @ 14.4 VDC, 2-Ohms 1 x 500WOutput Power @ 14.4 VDC, 4-Ohms 1 x 250WPower Supply Input Voltage 12.0VDC to 14.8VDCMono Class D Technology2-Ohms...

Pairs well with

$152.99 USD

Payment and security

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

Monoblock Class D Amplifier

Output Power @ 14.4 VDC, 2-Ohms 1 x 500W
Output Power @ 14.4 VDC, 4-Ohms 1 x 250W
Power Supply Input Voltage 12.0VDC to 14.8VDC
Mono Class D Technology
2-Ohms Mono load Capability
Marine Grade Nickel Plated RCA connectors
Variable 12db Low-pass crossover
Selectable 12dB Bass Boost
Variable Sub-sonic Filter
Marine Grade Conformal Coated Double Sided PCB
Compatible with any 4/2-Ohms Subwoofer
THD (1KHz @ 4-Ohms): 0.04%
Bandwidth (-3 dB): 18Hz - 22KHz
Damping Factor (1KHz @ 4-Ohms): 100
S/N ratio (as weighted @ 1 Volt): 99db
Input Sensitivity: .0.2MV - 6V
Minimum Load Impedance: 2-Ohms
Low-Pass filter range: 50Hz - 150Hz
Sub-Sonic Filter Range: 15Hz - 50Hz

Product specifications table
Specification name Specification Value
Amplifier/Booster suitable location Marine transport
Amplifier class D
Audio output channel 2
Color pattern Black, Blue
Connectivity technology Wired
Device interface RCA
Power source Vehicle electrical system
Suitable space Indoors, Outdoors

🚚 Fast Shipping. Easy Install.

  • Usually ships in 2–4 business days
  • Delivered pre-mounted and ready to install with basic tools
